PO4 – Trench heater without a fan for wet environment

  • body made from high quality stainless steel
  • high natural convection output
  • short response time
  • can be used in damp / wet environments (eg by the pool)
  • does not serve as a drain trough
  • it is not possible to install it with salt or otherwise aggressive water pools

Function

without a fan

heating

wet environment

Dimensions

303 mm

125 mm

900 / 1000 / 1250 / 1500 / 1750 / 2000 / 2250 / 2500 / 2750 / 3000 mm

368  W/m

Technical parameters

Input parameters for calculation

Length (mm)

Atypical length (mm)

Inlet water temperature

Outlet water temperature

Interior temperature (°C)

Output parameters

Q [W]
Performances
q [l/h]
Water flow
∆P [kPa]
Water pressure drop
V [l]
Heat exchanger water volume
Enter input parameters
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.
The technical parameters are set according to the relevant standards. In fact, they may vary depending on the location of the convector, the cover grille, the connection type.

Available grilles and accessories

Grille- aluminium

rolling - sparse

Grille- aluminium

segmented - sparse - high

Grille - st. steel

rolling - sparse (must be ordered with the convector)

Frame

standard

Frame

covering

Grille - aluminium - transverse

shade: SILVER

Grille - aluminium - transverse

shade: LIGHT BRONZE

Grille - aluminium - transverse

shade: DARK BRONZE

Grille - st. steel - transverse

shade: ST. STEEL
